Increases availability by allowing a trained user to perform upgrades and replacements of the batteries reducing Mean Time to Repair (MTTR)
Audible alarms
Provides notification of changing utility power and UPS power conditions
Automatic self-test
Periodic battery self-test ensures early detection of a battery that needs to be replaced
Cold-start capable
Provides temporary battery power when the utility power is out
Green mode
Patent-pending operating mode that bypasses unused electrical components in good power conditions to achieve very high operating efficiency without sacrificing any protection
Battery failure notification
Provides early-warning fault analysis on batteries enabling timely preventive maintenance
Battery replacement without tools
Enables fast battery replacement, lowering Mean Time to Repair (MTTR)
Safety-agency approved
Ensures the product has been tested and approved to work safely with the connected service provider equipment and within the specified environment
LCD graphics display
Text and mimic diagrams that display modes of operation, system parameters and alarms
Hot-swappable batteries
Ensures clean, uninterrupted power to protected equipment while batteries are being replaced
Battery-protected and surge-only outlets
Reserves power capacity and run time for connected equipment that require UPS battery back-up while providing surge only protection for less critical equipment
Boost and Trim Automatic Voltage Regulation (AVR)
Gives higher application availability by correcting low and high voltage conditions without using the battery (not available on all models)
Dataline surge protection
Provides protection of connected equipment from power surges on the data lines
Disconnected battery notification
Warns when a battery is not available to provide backup power
USB connectivity
Provides management of the UPS via a USB port (not available on all models)
Power-saving outlets
Automatically cuts power to idle equipment to conserve electricity
Automatic Voltage Regulation (AVR)
Automatically steps up low voltage and steps down high voltage to levels that are suitable for your equipment
Specifications
Summary
Product Description
APC Back-UPS RS LCD 550 Master Control - UPS - 330 Watt - 550 VA
Device Type
UPS - external
Weight
6.5 kg
Input Voltage
AC 230 V
Output Voltage
AC 230 V
Power Capacity
330 Watt / 550 VA
Input Connectors
1 x power IEC 60320 C14
Output connectors
3 x power IEC 60320 C13 (surge) , 3 x power IEC 60320 C13 (UPS and surge)
Battery Form Factor
Internal
Batteries Qty
1
Networking
USB
Colour
Black
Dimensions (WxDxH)
9.1 cm x 31 cm x 19.2 cm
Manufacturer Warranty
2-year warranty
Detailed Specification
General
Device Type
UPS - external
Battery Enclosure Type
Internal
Colour
Black
Power Device
UPS Technology
Line interactive
Input Voltage
AC 230 V
Input Voltage Range
AC 176 - 282 V
Frequency Provided
50/60 Hz
Input Connectors
1 x power IEC 60320 C14
Power Output Connectors Details
3 x power IEC 60320 C13 (surge) , 3 x power IEC 60320 C13 (UPS and surge)
Output Voltage
AC 230 V 50/60 Hz
Power Capacity
330 Watt / 550 VA
Dataline Surge Protection
Network - RJ-45
Output Waveform
Stepped approximation to a sinewave
Surge Suppression
Yes
Surge Energy Rating
355 Joules
Circuit Protection
Circuit breaker
Battery
Quantity
1
Recharge Time
12 hours
Networking
Remote Management Interface
USB
Miscellaneous
Features
Audible alarm, LCD display, Automatic Voltage Regulation (AVR)
